Overview

Deploy Vaultwarden Self Hosted HTTPS on Docker , WebSocket support, and an admin token. Per‑OS install commands are split; Add‑Ons are OS‑agnostic.

Prerequisites

Linux server with DNS to it; ports 80/443 open; sudo shell.

Quick Architecture

Variables

Before you copy: Customize values once; then run source /root/vars.sh to load them for all steps.

• VW_DOMAIN, EMAIL, VW_DATA, NGINX_SITE, VW_IMAGE, VW_ADMIN_TOKEN

sudo install -d -m 700 /root
cat <<'EOF' | sudo tee /root/vars.sh
export VW_DOMAIN="vault.example.com"
export EMAIL="[email protected]"
export VW_DATA="/var/lib/vaultwarden"
export NGINX_SITE="/etc/nginx/sites-available/vaultwarden.conf"
export VW_IMAGE="vaultwarden/server:latest"
export VW_ADMIN_TOKEN="$(openssl rand -hex 24)"
EOF
source /root/vars.sh

Step 1 — Install / Setup

Debian / Ubuntu

sudo apt update
sudo apt -y install docker.io nginx certbot   # Certbot install here (per‑OS)

RHEL / Rocky / Alma / CentOS Stream / Fedora

sudo dnf -y install docker nginx certbot      # Certbot install here (per‑OS)

Arch / Manjaro

sudo pacman -Syu --noconfirm docker nginx certbot   # Certbot install here (per‑OS)

openSUSE / SLE

sudo zypper refresh
sudo zypper install -y docker nginx certbot   # Certbot install here (per‑OS)

Step 2 — Base Configuration

sudo mkdir -p "$VW_DATA"
sudo docker run -d --name vaultwarden --restart unless-stopped   -p 127.0.0.1:8080:80   -v "$VW_DATA":/data   -e SIGNUPS_ALLOWED=true   -e ADMIN_TOKEN="$VW_ADMIN_TOKEN"   -e WEBSOCKET_ENABLED=true   "$VW_IMAGE"

Nginx TLS site (universal)

server {
  listen 80;
  server_name $VW_DOMAIN;
  location /.well-known/acme-challenge/ { root /var/www/_letsencrypt; }
  location / { return 301 https://$host$request_uri; }
}
server {
  listen 443 ssl http2;
  server_name $VW_DOMAIN;

  ssl_certificate     /etc/letsencrypt/live/$VW_DOMAIN/fullchain.pem;
  ssl_certificate_key /etc/letsencrypt/live/$VW_DOMAIN/privkey.pem;

  client_max_body_size 100m;
  proxy_set_header Host $host;
  proxy_set_header X-Forwarded-Proto https;
  proxy_set_header X-Real-IP $remote_addr;

  location /notifications/hub/negotiate { proxy_pass http://127.0.0.1:8080; }
  location /notifications/hub          { proxy_set_header Upgrade $http_upgrade; proxy_set_header Connection "upgrade"; proxy_pass http://127.0.0.1:8080; }
  location / { proxy_pass http://127.0.0.1:8080; }
}

Step 3 — Enable & Health Checks

sudo systemctl enable --now docker nginx
sudo docker ps --format "table {{.Names}}	{{.Status}}	{{.Ports}}" | grep -E '^vaultwarden\b' || echo "vaultwarden not running?"
sudo ss -tlnp | grep -E ':(80|443)\b'  # Check

Security / Hardening

Harden with these practices; snippets are optional and separate:

• Keep the app bound to 127.0.0.1:8080; all traffic goes through HTTPS Nginx.
• Rotate the admin token regularly.
• Restrict /admin to trusted IPs or a VPN.

Rotate admin token

export VW_ADMIN_TOKEN="$(openssl rand -hex 24)"
sudo docker stop vaultwarden && sudo docker rm vaultwarden
sudo docker run -d --name vaultwarden --restart unless-stopped   -p 127.0.0.1:8080:80   -v "$VW_DATA":/data   -e SIGNUPS_ALLOWED=true   -e ADMIN_TOKEN="$VW_ADMIN_TOKEN"   -e WEBSOCKET_ENABLED=true   "$VW_IMAGE"

Restrict /admin by IP

location /admin {
  allow 203.0.113.0/24;   # your office block
  deny  all;
  proxy_pass http://127.0.0.1:8080;
}

Performance & Optimization

• Enable HTTP/2 (already enabled) and proxy keepalive.
• Place data on SSD; monitor I/O latency (SQLite is file‑based).
• Reduce client_max_body_size if attachments are disabled.

Backup & Restore

Back up both the app data and Nginx config. Store off‑server.

Backup

sudo tar -C / -czf /root/vaultwarden-backup.tgz "$VW_DATA" "$NGINX_SITE"
ls -lh /root/vaultwarden-backup.tgz  # Check

Restore

sudo systemctl stop nginx
sudo docker stop vaultwarden
sudo tar -C / -xzf /root/vaultwarden-backup.tgz
sudo docker start vaultwarden
sudo systemctl start nginx
curl -s https://$VW_DOMAIN/ | head -n 1  # Check

Advanced Add-Ons

OS‑agnostic only.

(Add‑On) Automated Certificates (Certbot)

Use webroot ACME to request/renew certificates. Install Certbot per‑OS in Step 1; here we only run it.

sudo install -d -m 755 /var/www/_letsencrypt
sudo certbot certonly --webroot -w /var/www/_letsencrypt -d "$VW_DOMAIN" --email "$EMAIL" --agree-tos --no-eff-email
sudo certbot renew --dry-run  # Check

(Add‑On) SMTP Email

Enable email delivery for verification and invites.

sudo docker stop vaultwarden
sudo docker rm vaultwarden || true
sudo docker run -d --name vaultwarden --restart unless-stopped   -p 127.0.0.1:8080:80   -v "$VW_DATA":/data   -e SIGNUPS_ALLOWED=true   -e ADMIN_TOKEN="$VW_ADMIN_TOKEN"   -e WEBSOCKET_ENABLED=true   -e SMTP_HOST="smtp.example.com"   -e SMTP_FROM="$EMAIL"   -e SMTP_PORT=587   -e SMTP_SSL=true   -e SMTP_USERNAME="smtp-user"   -e SMTP_PASSWORD="smtp-password"   "$VW_IMAGE"

(Add‑On) Off‑server Backups (rclone to S3/MinIO)

Assumes rclone is installed and a remote (e.g., s3remote) is configured.

sudo tar -C / -czf /root/vaultwarden-$(date +%F).tgz "$VW_DATA"
rclone copy /root/vaultwarden-$(date +%F).tgz s3remote:backups/vaultwarden/  # Check

Troubleshooting (Top issues)

WebSocket not upgrading

grep -n "notifications/hub" "$NGINX_SITE"
sudo nginx -t && sudo systemctl reload nginx

Admin panel not accessible

sudo docker logs vaultwarden | tail -n 100 | sed -n '1,120p'

Key Takeaways & Next Steps

• HTTPS + WebSocket + admin token ready.
• Backups tested; optional add‑ons available.
• Harden /admin, keep everything updated.
